2023 Ford F-150 Engines

2022 Ford F-150 Engine Options

The 2022 Ford F-150 is engineered to deliver exceptional performance and towing capability to help you meet the demands of your busy days. The F-150 is available with six potent engines to provide excellent versatility and flexibility for various lifestyles. Which engine is suitable for your needs? Our team at Westfield Ford in Countryside, IL, has created this 2022 Ford F-150 engines guide for your research.

You can learn more about key features and technology available on the 2022 Ford F-150 with our in-depth F-150 review and F-150 trims guide. The 2022 Ford F-150 starts at $30,870 MSRP.

Explore our 2022 Ford F-150 inventory to find your desired model, then schedule a test drive to experience it in person. If you have any questions, our team is happy to assist when you contact us online or by phone at (708) 354-8600.

2022 Ford-150 Engines

Engineered to deliver potent performance and best-in-class towing and payload capacities, the six-engine lineup of the 2022 Ford F-150 includes various V6 and V8 engine options, including a new full hybrid V6, to ensure you have the ability to take on heavy-duty tasks with ease. Each engine is paired to a ten-speed automatic transmission with SelectShift®.

2022 Ford F-150 Horsepower

The 2022 Ford F-150 engines provide varying levels of performance from balanced horsepower and torque that are ideal for daily driving to fuel-efficient EcoBoost® technology, to adrenaline-inducing twin-turbocharged power. View the F-150 engines and specifications in the following table.

Engine	Horsepower	Torque
3.3L Ti-VCT V6	290 HP	265 lb.-ft.
2.7L EcoBoost V6	325 HP	400 lb.-ft.
5.0L Ti-VCT V8	400 HP	410 lb.-ft.
3.5L EcoBoost V6	400 HP	500 lb.-ft.
3.5L PowerBoost™ full hybrid V6	430 HP	570 lb.-ft.
High-Output 3.5L Ecoboost V6	450 HP	510 lb.-ft.

2022 Ford F-150 Towing Capacity

Built for heavy hauling, the 2022 Ford F-150 offers best-in-class towing and payload capacities. When the F-150 is configured as a super cab with an 8-foot bed or a SuperCrew® cab with a 5.5- or 6.5-foot bed and paired with the 3.5L EcoBoost V6 engine as well as the Max Trailer Tow Package, you’ll have the ability to tow a maximum of 14,000 pounds.

Equip the 5.0L Ti-VCT V8 engine on a regular cab with an 8-foot bed and the Heavy-Duty Payload Package for the maximum available payload capacity of 3,325 pounds. View the available towing and payload capacities of each engine in the following table.

Engine	Max. Conventional Towing	Max. Payload
3.3L Ti-VCT V6	8,200 lbs.	1,985 lbs.
2.7L EcoBoost V6	10,100 lbs.	2,480 lbs.
5.0L Ti-VCT V8	13,000 lbs.	3,325 lbs.
3.5L EcoBoost V6	14,000 lbs.	3,250 lbs.
3.5L PowerBoost full hybrid V6	12,700 lbs.	2,120 lbs.
High-Output 3.5L Ecoboost V6	8,200 lbs.	1,410 lbs.

2022 Ford F-150 Fuel Efficiency

When you need a pickup truck that provides optimal fuel economy combined with its performance and towing capabilities, the 2022 Ford F-150 delivers. View the EPA-estimated fuel economy specifications in the following table.

Engine	MPG
3.3L Ti-VCT V6	19 city/24 hwy
2.7L EcoBoost V6	20 city/26 hwy
5.0L Ti-VCT V8	17 city/24 hwy
3.5L EcoBoost V6	18 city/24 hwy
3.5L PowerBoost™ full hybrid V6	25 city/25 hwy
High-Output 3.5L Ecoboost V6	15 city/18 hwy

PowerBoost™ Full Hybrid V6

The class-exclusive 3.5L PowerBoost full hybrid V6 engine is innovatively engineered to give you the efficiency of gas and electric power while still being capable of towing up to 12,700 pounds when you need to. The 3.5L PowerBoost full hybrid V6 can be equipped with a 4x2 or 4x4 drivetrain and includes a 33-kilowatt electric motor.

2022 Ford F-150 for Sale

Discover the 2022 Ford F-150 for sale at Westfield Ford in Countryside, IL, when you browse our new inventory. If you have any questions, our team can assist when you contact us online or by phone at (708) 354-8600.

2021 Ford F-150 Engine Options, Drivetrains, & Cab Configurations in Illinois

The purpose-built 2021 Ford F-150 offers incredible versatility with six engine options, rear-wheel drive (RWD) or 4x4 drivetrains, and three cab configurations across six available models. When heavy hauling is part of your work or active lifestyle, the F-150 features the best-in-class available tow rating and best-in-class maximum payload capacity when properly equipped.

The regular cab is available with a 6.5- or 8-foot bed on the XL and XLT models. The extended SuperCab is available with a 6.5- or 8-foot bed on the XL, XLT, and Lariat models. The full four-door SuperCrew® is available with a 5.5- or 6.5-foot bed on all F-150 models.

If you’re considering this fully capable pickup truck, our team at Westfield Ford has created this guide to help you better compare the available engine options of the 2021 Ford F-150. Explore the 2021 Ford F-150 available in our current inventory and view our finance and lease offers for savings opportunities. Schedule a test drive or let our team of Ford experts assist you with questions by contacting us online or by phone at (877) 470-0298.

3.5L PowerBoost™ Full Hybrid V6 Engine

New for the 2021 Ford F-150 engine lineup is the class-exclusive 3.5L PowerBoost Full Hybrid V6 engine. Its precision-engineered gas and electric energy deliver excellent power, great fuel efficiency, plus impressive towing and payload capacities.

• 430 total system HP
• 570 lb.-ft. of total system torque
• 12,700 lbs. max. towing capacity
• 2,120 lbs. max. payload capacity
• 25 city / 26 hwy MPG
• Available on all F-150 models

3.0L Power Stroke® Turbo Diesel V6

The durable 3.0L Power Stroke Turbo Diesel V6 engine is built for the long haul. Excellent low-end torque makes heavy hauling effortless. The Power Stroke Turbo Diesel engine is equipped with a 4x4 drivetrain and is flex-fuel compatible up to a B20 biodiesel blend.

• 250 HP
• 440 lb.-ft. of torque
• 12,100 lbs. max. towing capacity
• 1,840 lbs. max. payload capacity
• 20 city / 27 hwy MPG
• Available on XL, XLT, Lariat, King Ranch®, and Platinum

3.5L EcoBoost® V6

The 3.5L EcoBoost V6 engine features the Ford port-fuel and direct-injection system (PFDI) to increase power. With virtually no turbo lag from its twin turbos, power is delivered on-demand. The 3.5L EcoBoost V6 offers a best-in-class available tow rating of 14,000 pounds.

• 400 HP
• 500 lb.-ft. of torque
• 14,000 lbs. max. towing capacity
• 3,250 lbs. max. payload capacity
• 18 city / 24 hwy MPG
• Standard on the Limited
• Available on the XL, XLT, Lariat, King Ranch, Platinum

5.0L Ti-VCT V8

The legendary 5.0L Ti-VCT V8 engine delivers naturally aspirated power when you need pure muscle for the toughest jobs. Variable displacement engine (VDE) technology cuts power to half the cylinders, allowing you to maximize fuel efficiency when you need it.

• 400 HP
• 410 lb.-ft. of torque
• 13,000 lbs. max. towing capacity
• 3,325 lbs. max. payload capacity
• 17 city / 24 hwy MPG
• Standard on the King Ranch and Platinum
• Available on the XL, XLT, and Lariat

2.7L EcoBoost V6

The 2.7L EcoBoost V6 delivers incredible power and towing capabilities despite being the lowest displacement engine in the lineup. The 2.7L EcoBoost provides the same brute muscle as its 3.5L counterpart with a compacted graphite iron engine block for ultra-durability.

• 325 HP
• 400 lb.-ft. of torque
• 10,100 lbs. max. towing capacity
• 2,480 lbs. max. payload capacity
• 20 city / 26 hwy MPG
• Standard on the Lariat
• Available on the XL and XLT

3.3L Ti-VCT V6

The 3.3L Ti-VCT V6 engine provides balanced horsepower and torque across the power band. For an F-150 engine that doesn’t need to take on strenuous jobs, the 3.3L Ti-VCT V6 is plentiful. Responsive performance and an available towing capacity of 8,200 pounds make this the ideal everyday powerhouse.

• 290 HP
• 265 lb.-ft. of torque
• 8,200 lbs. max. towing capacity
• 1,985 lbs. max. payload capacity
• 20 city / 24 hwy MPG
• Standard on the XL and XLT

Ten-Speed Automatic Transmission

All engines of the 2021 Ford F-150 lineup feature a ten-speed automatic transmission. For the 3.5L PowerBoost Full Hybrid V6 engine, the transmission includes an integrated 33-kilowatt electric motor. Exceptional performance and throttle-response ensure power offsets the driving conditions. Take on rugged terrain, unfavorable weather conditions, and tow with ease using selectable drive modes such as Normal, Eco, Sport, Tow/Haul, Slippery, and Trail equipped on all F-150 models. If you opted for an F-150 4x4, additional terrain-specific drive modes include Deep Snow/Sand, Mud/Ruts, and Rock Crawl with the FX4 Off-Road package.

Performance Ratings

The 2021 Ford F-150 engine lineup features two best-in-class performance ratings for full-size pickups, plus a class-exclusive.

• 3.5L EcoBoost V6 - best-in-class available tow rating
• 5.0L Ti-VCT V8 - best-in-class maximum payload rating
• 3.5L PowerBoost Full Hybrid V6 Engine - class-exclusive

Finance or Lease the 2021 Ford F-150 at Westfield Ford in Countryside, IL

Discover your new 2021 Ford F-150 in our current inventory. Pair your favorite F-150 with one of our available finance and lease offers for a great deal when you purchase from Westfield Ford in Countryside, IL. When you’re ready to get behind the wheel, our professional finance team is available to help you through the process. If you have questions, contact us online or by phone at (877) 470-0298.

2020 Ford F-150: Engine Options, Drivetrains, Axles, and Cab Configurations in Countryside, IL

If you’re shopping for a new truck, you’ll likely be concerned with your new vehicle’s performance, as well as towing and hauling capabilities. Every 2020 Ford F-150 model is equipped to help you get the most out of your workday, but deciding which configuration is for you can be tricky. The team at Westfield Ford can help, with our 2020 Ford F-150 engine options guide. If you have additional questions for the team at our dealership in Countryside, IL, call (877) 470-0298 or contact us online.

3.5L EcoBoost®

Available on most F-150 trims, the 3.5L EcoBoost® promises best-in-class torque outputs. Low-end and peak power and acceleration result in stellar towing potential and payload capacity for this Ford F-150 engine. 3.5L EcoBoost® performance specs are as follows:

• 375 HP
• 470 lb.-ft. of torque
• 13,200 lbs. max. towing capacity
• 3,230 lbs. max. payload capacity
• 18 city / 25 hwy MPG

3.0L Power Stroke® Turbo Diesel

The 3.0L Power Stroke® is the only diesel configuration among the 2020 F-150 engine lineup. With this engine under the hood, you’ll experience impressive fuel efficiency and useful towing capabilities. 3.0L Power Stroke® performance specs include:

• 250 HP
• 440 lb.-ft. of torque
• 11,300 lbs. max. towing capacity
• 1,980 lbs. max. payload capacity
• 22 city / 30 hwy MPG

High-Output 3.5L EcoBoost®

Standard in the F-150 Raptor and Limited, the High-Output 3.5L EcoBoost® includes a number of refinements compared to the base 3.5L EcoBoost® to maximize this powertrain’s performance. H.O. 3.5L EcoBoost® performance specs include:

• 450 HP
• 510 lb.-ft. of torque
• 11,100 lbs. max. towing capacity
• 1,520 lbs. max. payload capacity
• 17 city / 22 hwy MPG

2.7L Turbocharged EcoBoost®

The smallest of the 2020 F-150 engines, the 2.7L EcoBoost® delivers incredible power for its size, outpacing the torque outputs of some competitors’ V8 engines. Performance specs for this capable engine are as follows:

• 325 HP
• 400 lb.-ft. of torque
• 9,000 lbs. max. towing capacity
• 2,470 lbs. max. payload capacity
• 20 city / 26 hwy MPG

5.0L Ti-VCT V8

The Ford F-150 5.0L V8 promises to make tough tasks look easy. This legendary configuration is built to work as hard as you do, with an excess of power and capability. 5.0L Ti-VCT V8 performance specs include:

• 395 HP
• 400 lb.-ft. of torque
• 11,500 lbs. max. towing capacity
• 3,270 lbs. max. payload capacity
• 17 city / 23 hwy MPG

3.3L Ti-VCT V6

If you don’t require unrelenting power for your day-to-day routine, the 3.3L Ti-VCT V6 engine may be for you. This F-150 engine will tow over 7,000 lbs. without overwhelming the driver with extra power and torque. 3.3L V6 performance specs are as follows:

• 290 HP
• 265 lb.-ft. of torque
• 7,700 lbs. max. towing capacity
• 1,990 lbs. max. payload capacity
• 19 city / 25 hwy MPG

Ten-Speed Automatic Transmission

Most F-150 engines are paired with an advanced ten-speed automatic transmission. This enhanced transmission boosts overall performance and low to mid-range acceleration. Additionally, this transmission allows you to match your truck’s performance to the current conditions with a drive mode select system.

Performance Ratings

A number of 2020 F-150 engines boast best-in-class performance ratings. The 5.0L V8 delivers best-in-class payload, and the 3.5L EcoBoost® tops the competition when comparing torque. Finally, the High Output 3.5L EcoBoost® produces best-in-class horsepower when looking at full-size pickups.

Drivetrain Types

While the 2020 F-150 Raptor is standardly equipped with a 4x4 drivetrain, every other F-150 offers the choice between 4x2 and 4x4 drivetrains. Depending on your hauling or off-road needs, the added capability of 4x4 may be useful.

Transmissions

The base 3.3L V6 engine features a six-speed automatic transmission, while every other powertrain is paired with a ten-speed automatic transmission. Both transmissions offer SelectShift® capability, which improves responsiveness and performance.

Finance or Lease the 2020 Ford F-150 Today!

If you’re looking for 2020 Ford F-150 models for sale in Countryside, IL, Westfield Ford is the place to go! Scroll through our F-150 inventory, and pair your favorite pickup with a monthly lease or finance special to lock in a great price. To set up a test drive appointment or learn more, call us at (877) 470-0298 or send us a message online.
